Wok Ranges · Cross-Jet Burner

Name: SWENZA Wok Ranges · Cross-Jet Burner
Brand: SWENZA

13" & 16" · 120,000–160,000 BTU/h

Cross-jet burners for maximum crossfire heat in a compact, single-hole wok station.

Certification

ETLNSF

2 models

CP-JWOK13CP-JWOK16

Request a quotation WhatsApp

Key features

Tap + to add an individual model to your inquiry list. Imperial and metric values as published in our catalog.

Model	Gas Type	Jet Burners	Total BTU	Overall Dimensions	Net Weight	Package Size	Shipping Weight	Add to inquiry
CP-JWOK13	NG / LP	23	120,000	17.5"×24.1"×34"44.3×61.3×86.5cm	59 lbs / 27 kg	18.1"×22.8"×24.4"46×58×62cm	75 lbs / 34 kg
CP-JWOK16	NG / LP	32	160,000	17.5"×24.1"×35.2"44.3×61.3×89.5cm	64 lbs / 29 kg	18.1"×22.8"×25.6"46×58×65cm	79 lbs / 36 kg

For commercial installation only; not intended for household use.
3/4" NPT rear gas connections. Supply gas pressure not to exceed 14" W.C. (1/2 PSI)
Natural gas: operating pressure 5.0" W.C., recommended supply 7–9" W.C.
Propane: operating pressure 10.0" W.C., recommended supply 11–12" W.C.
A gas pressure regulator supplied with unit must be installed
An adequate ventilation system is required for Commercial Cooking Equipment
6" clearance required at both sides and rear from combustible construction.
