Charbroilers
Gas Charbroilers · CE
12" – 48" · 8.5 kW per burner
CE-approved charbroilers with flame-failure protection and U-shaped burners every 12".
Certification
CE
4 models
CP-UCB12CP-UCB24CP-UCB36CP-UCB48
- Spec sheet & drawings on request
- Private label available
- Built for EU, UK & international
Key features
- Flame-failure protection
- U-shaped burner every 12", 8.5 kW each
- G20, G30 and G31 gas categories
- Stainless steel cabinet; cool-to-the-touch front edge
- Removable full-width crumb tray
At a glance
- Product family
- Charbroilers
- Models in series
- 4
- Market
- Europe & International
- Certification
- CE
- Gas
- G20 / G30/G31
- Drawings
- Dimension drawing below
Technical data
Tap + to add an individual model to your inquiry list. Imperial and metric values as published in our catalog.
| Model | Gas Type | Burners | Total kW | Overall Dimensions | Net Weight | Package Size | Shipping Weight | Add to inquiry |
|---|---|---|---|---|---|---|---|---|
| CP-UCB12 | G20 / G30/G31 | 1 | 8.5 | 30.5×72.8×39.4cm | 31 kg | 40×85×49cm | 46 kg | |
| CP-UCB24 | G20 / G30/G31 | 2 | 17 | 60.9×72.8×39.4cm | 50 kg | 70×85×49cm | 72 kg | |
| CP-UCB36 | G20 / G30/G31 | 3 | 25.5 | 91.4×72.8×39.4cm | 70 kg | 100×85×49cm | 97 kg | |
| CP-UCB48 | G20 / G30/G31 | 4 | 34 | 122×72.8×39.4cm | 90 kg | 130×85×49cm | 122 kg |
Dimension drawing
Open full size
Installation notes
- For commercial installation only; not intended for household use.
- 3/4" NPT rear gas connections. Inlet pressure as below: G20 at 20mbar-I2H.I2EandI2E+; G30/G31 at 30mbar-I3B/P(30); G30 at 28-30mbar G31 at 37 mbar-I3+(28-30-37)
- An adequate ventilation system is required for Commercial Cooking Equipment
- 6" clearance required at both sides and rear from combustible construction.
